Multi-Zone Temperature Chamber

Arbin’s Multi-Zone Temperature Chamber (MZTC) is a battery test chamber with 4 or 8 independent temperature chambers in 1 for cells up to 60A. Insulation and protection between each chamber provides greater temperature control and a safe testing environment by isolating each cell or pair of cells, as well as making connections easy.

Multi-Zone Temperature Chamber showing inside of chamber
Arbin Battery Test Chamber

Stable, Uniform Temperature for Cell Testing

Arbin's MZTC features eight compact, independent temperature chambers that employ state-of-the-art thermal management. The small, independent chambers ensure a stable and uniform temperature for all cells without temperature fluctuation that oversized chambers suffer. Isolating cells this way provides greater independence to access and monitor the devices under test, and prevents a weak or failed cell from affecting others during testing.

Advantages
  • State-of-the-art thermal management techniques ensure a stable and uniform temperature for all cells
  • Increase independence to access and monitor devices under test with cells isolated by temperature
  • Prevent weak or failed cells from affecting others during testing
  • Over 10 different battery trays accommodate a variety of cell types and make connections easy
Applications
Safety

Coin Cell Trays

Battery Tray Holder for 5A coin cell with 2 channels

Two Channel Coin Cell Tray

Number of Cells: 2
Max Current: 5A
Cell Size:
- Diameter: 10mm to 30mm
- Height: <= 7mm
2 x PT100 Inputs







Battery Tray Holder for 5A coin cell with 4 channels

Four Channel Coin Cell Tray

Number of Cells: 4
Max Current: 5A
Cell Size:
- Diameter: 10mm to 30mm
- Height: <= 7mm
1 x PT100 Input

MZTC_Universal+3E-2Ch

Three Electrode Tray

Compatible with 2 channel Universal tray
Number of Cells: 2
Max Current: 5A

Cell Size:
- Diameter: 10mm to 30mm
- Height: <= 7mm
1 x PT100 Inputs

Cylindrical Cell Trays

Battery Tray Holder for 10A cylindrical cell with 2 channels

10A Cylindrical Cell Tray

Number of Cells: 2
Max Current: 10A
Cell Size:
- Diameter: 18mm to 32mm
- Length: 55mm to 80mm





Battery Tray Holder for 30A cylindrical cell with 1 channel

30A Cylindrical Cell Tray

Number of Cells: 1
Max Current: 30A
Cell Size:
- Diameter: 18mm to 50mm
- Length: 55mm to 100mm



Battery Tray Holder for 60A cylindrical cell with 1 channel

60A Cylindrical Cell Tray

Number of Cells: 1
Max Current: 60A
Cell Size:
- Diameter: 18mm to 50mm
- Length: 55mm to 100mm

Universal Cell Trays & Holders

Battery Tray Holder for 10A universal cell with 2 channels

10A Universal Cell Tray

Number of Cells: 2
Max Current: 10A





Battery Tray Holder for 60A universal cell with 1 channel

60A Universal Cell Tray

Number of Cells: 1
Max Current: 60A



PouchCellHolder

Pouch Cell Holder

MZTC-AlligatorClips

Alligator Clip

MZTC-3EAlligatorClips

3E Alligator Clip

Scalable Rack Solutions

The Multi-Zone Temperature Chamber (MZTC) can be provided as a benchtop unit or built-in rack solution. The rack can be scaled to fit individual laboratories, with options ranging from two up to six chamber.

MZTC-Rack-6Chamber
